Hot Rolled Stainless Steel Coil
Product Definition
Hot Rolled Stainless Steel Coil is produced by rolling stainless steel slabs at temperatures above the recrystallization range, resulting in a stable metallurgical structure and reliable mechanical properties for industrial fabrication.
This material is used in structural and heavy-duty engineering applications where consistency, durability, and long-term supply stability are required in procurement decisions.
Typical applications include construction engineering, petrochemical systems, energy equipment, shipbuilding, industrial machinery, and heavy fabrication industries.
Manufacturing System
Our production system is based on an integrated furnace-controlled manufacturing process:
- Continuous casting → hot rolling production line
- Furnace-based heat number batch control system
- Multi-line rolling capacity for industrial production
- Controlled cooling after hot rolling
- Industrial coil finishing and inspection process
- Annual production capacity: 50,000 tons
Production Control Logic
Each coil is produced under a furnace heat number. All coils within the same heat share identical chemical composition range and are tracked throughout production, inspection, and shipment.
Product Specifications (Standard Supply Range)
Grades: 201 / 304 / 304L / 316L / 321 / 430
Thickness: 2.0mm – 16.0mm
Width: 1000mm – 2000mm (slitting available)
Coil Inner Diameter: 508mm / 610mm
Surface Finish: No.1 (Hot Rolled, Pickled)
Edge Type: Mill Edge / Slit Edge
Standards: ASTM A240 / ASTM A480 / EN 10088 / JIS G4304
Chemical Composition & Traceability System
All chemical compositions are verified through spectrometric testing per furnace heat.
Example – Grade 304:
Carbon (C): ≤ 0.08%
Chromium (Cr): 18.0% – 20.0%
Nickel (Ni): 8.0% – 10.5%
Manganese (Mn): ≤ 2.0%
Silicon (Si): ≤ 1.0%
Heat Number Traceability System (Audit-Level Structure)
Each coil is marked with a heat number linked to:
Raw material batch record
Furnace melting report
Rolling process parameters
Laboratory test results
Final inspection report
Shipment documentation
Mechanical Properties
- Tensile Strength: ≥ 515 MPa
- Yield Strength: ≥ 205 MPa
- Elongation: ≥ 40%
Engineering Interpretation
Hot rolling combined with controlled cooling refines grain structure and improves ductility, ensuring stable performance in welding, bending, stamping, and structural fabrication processes.
Quality Control System (Inspection & Verification Workflow)
Production Flow (Actual Process)
Continuous Casting → Hot Rolling → Controlled Cooling → Pickling → Coiling → Inspection → Packaging
Inspection System
- Spectrometric chemical analysis per furnace heat
- Ultrasonic Testing (UT) for internal quality verification
- Surface inspection before shipment
- Thickness tolerance control (±0.1mm / ±0.2mm)
- Coil weight and dimensional verification
- Batch-based traceability control
Third-Party Inspection (Optional)
- SGS
- Bureau Veritas (BV)
- TÜV Rheinland
Documentation Package
Each shipment can include:
- Mill Test Certificate (EN 10204 3.1 / 3.2 optional)
- Chemical composition report per heat number
- Mechanical test report
- Dimensional inspection report
- Production traceability records
Procurement Risk Statement
Production is controlled under stable furnace and rolling parameters to reduce batch variation and ensure consistent performance in downstream fabrication.
Application & Supply Scope
Export Regions
- Middle East: Petrochemical and infrastructure projects
- Southeast Asia: Industrial manufacturing and energy systems
- South America: Heavy fabrication industries
- Africa: Infrastructure development projects
- Europe: Industrial engineering applications
Application Industries
- Structural steel engineering
- Petrochemical systems
- Offshore and marine engineering
- Energy equipment manufacturing
- Industrial machinery production
Packaging & Logistics (Export Standard)
- Anti-corrosion wrapping (PVC film + kraft paper)
- Steel band reinforcement for coil stability
- Wooden pallet or steel frame packaging options
- Container loading optimization for sea freight
Certifications & Compliance
- ISO 9001 Quality Management System
- EN 10204 3.1 / 3.2 Mill Test Certificates
- Third-party inspection (SGS / BV / TÜV optional)
- Full heat number traceability system
Supplier Profile
We operate as an industrial stainless steel supplier based on furnace-controlled batch production and standardized quality management systems.
Core operational structure includes:
Furnace-based batch production control
Chemical composition stability management
Full traceability documentation system
Multi-region export experience
Industrial supply capability for long-term procurement
FAQ
Q: What is Hot Rolled Stainless Steel Coil used for?
A: Used in construction, petrochemical systems, shipbuilding, energy equipment, industrial machinery, and heavy fabrication industries.
Q: What is the difference between hot rolled and cold rolled stainless steel?
A: Hot rolled is produced at high temperature with better ductility and lower cost. Cold rolled provides higher surface finish and tighter tolerances.
Q: Do you provide Mill Test Certificates?
A: Yes. EN 10204 3.1 or 3.2 certificates are provided with full heat number traceability.
Q: How is quality controlled?
A: Through spectrometric testing, ultrasonic inspection, dimensional control, and furnace-based batch traceability.
Q: Can third-party inspection be arranged?
A: Yes. SGS, BV, and TÜV inspections are available before shipment.
Q: What is your delivery time?
A: Typically 15–30 days depending on specification.
Q: Do you support customization?
A: Yes. Thickness, width, coil weight, and slitting can be customized.
Q: Which markets do you export to?
A: Middle East, Southeast Asia, South America, Africa, and Europe.
Q: How is traceability ensured?
A: Each coil is linked via heat number to furnace records, raw materials, test results, and shipment documentation.
Q: Do you support long-term contracts?
A: Yes. Annual and multi-year supply agreements are available.
